D1000 AC Drive

Get a Price/Quote

MOQ : 1 Unit

D1000 AC Drive Specification

Humidity %
95 (non-condensing)

Operating Temperature
-10C to 50C

Shape
Rectangular

Surface Finish
Matte

Power Factor
0.98

Mounting Type
Wall Mount

Efficiency
96%

Overheating Protection
YES

Insulation Material
Epoxy

Feature
High Reliability, Compact Design

IP Rating
IP55

Product Type
AC Drive

Application
Electrical

Protection Level
IP55

Frequency (MHz)
50/60

Rated Voltage
380-480 V

Energy Consumption
Low

Output Type
Multiple

Color
Grey

Dimension (L*W*H)
330 x 180 x 200 mm

Weight
6.5 kg

Warranty
1 Year

Size
Standard

Phase
Three Phase

Input Voltage
380-480 V

Material
ABS Plastic

No Of Poles
3

Protection Functions
Overcurrent, Short Circuit, Undervoltage, Overvoltage, Overload, Phase Loss

Storage Temperature
-25C to 70C

Display
Digital LED Display

Braking Unit
Built-in

Cooling Method
Forced Air Cooling

Communication Interface
RS485 (Modbus-RTU)

Software Compatibility
Windows Supported

Start Up Torque
150% at 1 Hz

Altitude
1000 m (without derating)

EMC Filter
Built-in

Response Time
<5 ms

Overload Capacity
150% for 60 Seconds

Display Language
English

Drive Technology
IGBT Inverter

Control Panel
Integrated

Control Method
V/F and Vector Control

Motor Power Supported
5.5 kW (7.5 HP)

Noise Level
<65 dB

Relative Permittivity
4.2

Supply Frequency Tolerance
5%

Weight With Packing
7.2 kg

Vibration Tolerance
0.6 mm

D1000 AC Drive Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
7 - 10 Days

Main Domestic Market
All India

About D1000 AC Drive

The D1000 AC Drive is designed to offer reliable and efficient control for a wide range of AC motor applications. They are built to handle industrial environments and reduce maintenance needs. These are designed with energy-saving technologies to help reduce power consumption and lower operational costs. This is designed to be compact, making it suitable for installations where space is limited. The D1000 series is particularly well-regarded for its balance of performance, ease of use, and versatility. D1000 AC Drive often comes with an intuitive keypad and display, making setup and programming straightforward.

Advanced Control and Start-Up Performance

The D1000 AC Drive utilizes both V/F and Vector Control technologies, delivering precise speed and torque control for industrial motors. With start-up torque rated at 150%% at 1Hz, it ensures reliable operation even under heavy-load scenarios, making it a leader in demanding electrical environments.

User-Friendly Display and Connectivity

Featuring a digital LED display and integrated control panel, the D1000 makes monitoring and adjustments intuitive. RS485 interface with Modbus-RTU protocol provides reliable communication with automation systems, ensuring efficient process integration and remote management.

Comprehensive Protection and Durability

Equipped with built-in protection functions such as overcurrent, short circuit, undervoltage, overload, and overheating protection, the D1000 safeguards your equipment. Its IP55 rating and matte-finish ABS casing guarantee durability in harsh industrial settings.

FAQs of D1000 AC Drive:

Q: How can I install the D1000 AC Drive for optimal performance?

A: Install the D1000 AC Drive on a flat surface using the wall mount design, ensuring an ambient operating temperature between -10C to 50C and altitude not exceeding 1000 m. Proper airflow must be maintained due to the forced air cooling method.

Q: What advantages does the Vector Control method offer over V/F control in the D1000 AC Drive?

A: Vector Control provides superior dynamic performance, precise torque regulation at low speeds, and rapid response times (<5 ms) compared to traditional V/F control, enhancing the drives efficiency and reliability in critical applications.

Q: When is the built-in braking unit utilized during operation?

A: The built-in braking unit activates during rapid deceleration or emergency stops, allowing safe and controlled energy dissipation and preventing overloads or motor damage in high-inertia systems.

Q: Where can I view or adjust operational parameters on the D1000 AC Drive?

A: Operational data and parameter settings can be accessed and adjusted directly via the integrated digital LED display and control panel in English, making real-time monitoring and configuration straightforward.

Q: What process ensures data communication between the D1000 AC Drive and external systems?

A: The drive employs RS485 (Modbus-RTU) for robust, standardized data exchange, enabling seamless integration with PLCs, HMIs, and Windows-compatible management software for remote control and diagnostics.

Q: How does the D1000 AC Drive benefit industrial applications regarding reliability?

A: With advanced protection functions, a high power factor of 0.98, 96%% efficiency, and IP55 enclosure, the D1000 minimizes downtime, reduces energy costs, and improves the longevity of electrical motors even in challenging settings.
